SKU: 550627

GTIN: 4052568094584

Все характеристики

Technical Data
Grid dimension	26
Mounting position	optional
Max. number of valve positions	10
Max. number of pressure zones	2
Burst pressure	725
Operating pressure	-0.910
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-550
Ambient temperature	-550
Max. tightening torque for valve mounting	2.034
Product weight	900.963
Type of mounting in-line valve manifold	With through-hole
Mounting method for valve	Via female thread
Pneumatic connection, port 1	3/8 NPT
Pneumatic connection, port 3	3/8 NPT
Pneumatic connection, port 5	3/8 NPT
Note on materials	RoHS-compliant
Material manifold rail	Wrought aluminium alloy
