| Technical Data |
|
| Valve function |
Sound pressure control function |
| Selection of additional functions |
With silencer |
| Pneumatic connection, port 1 |
G1/2 |
| Adjustment component |
Slotted head screw |
| Type of mounting |
Screw-in |
| Standard nominal flow rate in flow control direction |
3600 |
| Standard flow rate 0.6->0 MPa (6->0 bar, 87->0 psi) |
04300 |
| Operating pressure |
010 |
| Ambient temperature |
-1070 |
| Mounting position |
optional |
| Symbol |
00991451 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Media temperature |
-1070 |
| Product weight |
75 |
| Material screwed plug |
Wrought aluminium alloy |
| Note on materials |
RoHS-compliant |
| Material seals |
NBR |
| Material adjusting screw |
Brass |
