| Technical Data |
|
| Valve function |
Sound pressure control function |
| Selection of additional functions |
With silencer |
| Pneumatic connection, port 1 |
R1/4 |
| Adjustment component |
Knurled screw |
| Type of mounting |
Screw-in |
| Standard flow rate 0.6->0 MPa (6->0 bar, 87->0 psi) |
0420 |
| Operating pressure |
010 |
| Ambient temperature |
060 |
| Type of seal on screwed plug |
Coating |
| Mounting position |
optional |
| Symbol |
00991451 |
| Operating pressure complete temperature range |
010 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Media temperature |
060 |
| Product weight |
25 |
| Material shock absorber insert |
PE |
| Material screwed plug |
Nickel-plated brass |
| Note on materials |
RoHS-compliant |
| Material adjusting screw |
Nickel-plated brass |
