SKU: 10191
GTIN: 4052568111687
Все характеристики
| Technical Data | |
| Valve function | 3/2 open, monostable |
| Type of actuation | Mechanical |
| Standard nominal flow rate (standardised to DIN 1343) | 120 |
| pneumatic working port | G1/8 |
| Operating pressure | 3.58 |
| Design | Piston seat |
| Type of reset | Mechanical spring |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of piloting | Direct |
| Flow direction | Non-reversible |
| Symbol | 00991107 |
| lap | Overlap |
| Explosion protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:-] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -1060 |
| Actuating force | 8 |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Material cover | POM |
| Material seals | NBRTPE-U(PU) |
| Material housing | Aluminium |
