SKU: 6817
GTIN: 4052568001384
Все характеристики
| Technical Data | |
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Manual |
| Standard nominal flow rate (standardised to DIN 1343) | 65 |
| Operating pressure | -0.958 |
| Design | Poppet valve with spring return |
| Type of reset | Mechanical spring |
| Nominal size | 2 |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of piloting | Direct |
| Flow direction | Non-reversible |
| Symbol | 00991292 |
| lap | Overlap |
| Explosion protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -1060 |
| Actuating force | 12 |
| Product weight | 40 |
| Type of mounting | Front panel mountingWith through-hole |
| Pneumatic connection, port 1 | M5 |
| Material seals | NBR |
| Material housing | PolymerBrass |
