SKU: 6758

GTIN: 4052568001377

Все характеристики

Technical Data
Valve function	3/2-way, closed, monostable
Standard nominal flow rate (standardised to DIN 1343)	80
pneumatic working port	M5
Operating pressure	-0.958
Design	Poppet seat
Nominal size	2
Type of piloting	Direct
Symbol	00991100
Operating medium	Compressed air to ISO 8573-1:2010 [-:-:-]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-1060
Actuating force	8
Product weight	37
Type of mounting	With through-hole
Pneumatic connection, port 1	M5
Pneumatic connection, port 2	M5
Material seals	NBR
Material housing	Die-cast zinc
