SKU: 7843

GTIN: 4052568008772

Все характеристики

Technical Data
Valve function	3/2-way, closed, monostable
Type of actuation	Mechanical
Standard nominal flow rate (standardised to DIN 1343)	60
pneumatic working port	PK-3
Operating pressure	-0.958
Design	Poppet valve with spring return
Type of reset	Mechanical spring
Nominal size	1.8
Sealing principle	Soft
Mounting position	optional
Type of piloting	Direct
Symbol	00991095
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-1060
Actuating force	6
Product weight	7
Type of mounting	With through-hole
Pneumatic connection, port 1	PK-3
Pneumatic connection, port 2	PK-3
Material housing	PolymerBrass
