SKU: 158496
GTIN: 4052568125226
Все характеристики
| Technical Data | |
| Design | Mechanical sequence counter with pneumatic drive |
| Switch-off pressure | 0.1 |
| Operating pressure | 26 |
| Switch-on pressure | 1.6 |
| Standard nominal flow rate (standardised to DIN 1343) | 50 |
| Adjustable delay time | 0.22 |
| Pause duration for reset | 200 |
| Repetition accuracy of time setting | ± 0.3 s |
| Explosion protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation not possible |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Degree of protection | IP54With protective cap and panel frameTo IEC 60529 |
| Ambient temperature | -1560 |
| Product weight | 50 |
| Type of mounting | Front panel mounting |
| Pneumatic connection | Female thread M5 |
| Note on materials | RoHS-compliant |
| Material housing | ABS |
Приемущества
| Complete system offering control components with all the functions required for pneumatic sequence control |
| For control cabinet installation |
| Fast replacement of components |
| Mechanical sequence counter with pneumatic drive |
| Adjustable delay time |
| Available with protective cap |
Документы
| PZVT_EN.PDF |
| Datasheet |
