SKU: 153484
GTIN: 4052568035006
Характеристики
| Valve function | 2/2 bistable |
| Pneumatic connection, port 1 | QS-6 |
| Pneumatic connection, port 2 | QS-6 |
| Standard nominal flow rate (standardised to DIN 1343) | 533 |
| Operating pressure | -1, 10 |
Все характеристики
| Technical Data | |
| Valve function | 2/2 bistable |
| Pneumatic connection, port 1 | QS-6 |
| Pneumatic connection, port 2 | QS-6 |
| Type of actuation | Manual |
| Type of mounting | In-line installation |
| Standard nominal flow rate (standardised to DIN 1343) | 533 |
| Nominal size | 4 |
| Operating pressure | -110 |
| Ambient temperature | 060 |
| Material housing | PBTP |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Sealing principle | Soft |
| Design | Ball valve |
| Symbol | 00991458 |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 12 |
| Note on materials | RoHS-compliant |
Приемущества
| Shut-off valve, manually operated |
| In-line installation, can be screwed in, bulkhead fitting |
| Variants: thread at both ends, push-in connector at both ends, thread/push-in connector |
Документы
| QH_QS_EN.PDF |
| Datasheet |
