| Technical Data |
|
| Valve function |
Non-return function |
| Pneumatic connection, port 1 |
G1/2 |
| Pneumatic connection, port 2 |
G1/2 |
| Type of mounting |
Screw-in |
| Operating pressure |
0.412 |
| Ambient temperature |
-1060 |
| Material housing |
Anodised wrought aluminium alloy |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Mounting position |
optional |
| Symbol |
00991455 |
| Standard nominal flow rate 1->2 (6-5) |
5500 |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Storage temperature |
-1060 |
| Media temperature |
-1060 |
| Pilot medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Max. tightening torque |
40 |
| Product weight |
58.3 |
| Note on materials |
RoHS-compliant |
| Material seals |
NBR |
