SKU: 8193270

GTIN: 4052568641351

Все характеристики

Technical Data
Valve function	Non-return function
Pneumatic connection, port 1	QS-6
Pneumatic connection, port 2	QS-6
Pilot air port 21	QS-6
Type of actuation	Manual
Standard nominal flow rate (standardised to DIN 1343)	260
Operating pressure	10
Pilot pressure	29145
Ambient temperature	-1060
Material housing	PBT
Housing colour	grey
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Mounting position	optional
Type act., cont. n.-r. func.	Pneumatic
Manual exhaust function	Non-detenting
Symbol	00991957
Operating pressure complete temperature range	0.210
Standard flow rate 1->2 (6-0)	500
Standard nominal flow rate 1->2 (6-5)	260
Switching time off	9
Switching time on	6
Explosion protection	Zone 2 (ATEX)Zone 22 (ATEX)
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Storage temperature	-2070
Media temperature	-1060
Pilot medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Product weight	23.3
Material covering	ES-BE
Note on materials	RoHS-compliant
Material cover	PBT
Material seals	NBR
Material release ring	POM
