SKU: 8193272

GTIN: 4052568641375

Все характеристики

Technical Data
Valve function	Piloted non-return function
Selection of additional functions	Manually exhausted
Pneumatic connection, port 1	QS-4
Pneumatic connection, port 2	G1/8
Pilot air port 21	QS-4
Type of mounting	Screw-in
Operating pressure	0.210
Pilot pressure	29145
Ambient temperature	-1060
Material housing	PBT
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Mounting position	optional
Type act., cont. n.-r. func.	Pneumatic
Manual exhaust function	Non-detenting
Symbol	00991957
Rotatability	360°/no continuous swivelling permissible
Operating pressure complete temperature range	2.9145
Standard flow rate 1->2 (6-0)	500
Standard nominal flow rate 1->2 (6-5)	260
Switching time off	9
Switching time on	6
Explosion protection	Zone 2 (ATEX)Zone 22 (ATEX)
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-1060
Pilot medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Nominal torque	6
Tolerance for nominal tightening torque	± 20%
Product weight	27.9
Material covering	ES-BE
Note on materials	RoHS-compliant
Material cover	PBT
Material seals	NBR
Material hollow bolt	Wrought aluminium alloy
Material release ring	POM
