| Technical Data |
|
| Valve function |
AND function |
| Pneumatic connection, port 1 |
G1/8 |
| Pneumatic connection, port 2 |
G1/8 |
| Type of mounting |
With through-hole |
| Standard nominal flow rate (standardised to DIN 1343) |
550 |
| Operating pressure |
110 |
| Ambient temperature |
-1060 |
| Material housing |
Wrought aluminium alloyAnodised |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Nominal size |
4.5 |
| Mounting position |
optional |
| Symbol |
00991461 |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Media temperature |
-1060 |
| Product weight |
45 |
| Pneumatic connection, port 3 |
G1/8 |
| Note on materials |
RoHS-compliant |
| Material seals |
NBR |
