| Application |
|
| Design |
housing module |
| Electrical data |
|
| Operating voltage |
24...30 DC |
| Current consumption |
< 20 |
| Reverse polarity protection |
yes |
| Inputs / outputs |
|
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Inputs |
|
| Number of PWM inputs |
1 |
| PWM frequency inputs |
122 |
| Outputs |
|
| Number of analog outputs |
1 |
| Analog voltage output |
0...5 |
| Operating conditions |
|
| Ambient temperature |
-40...85 |
| Note on ambient temperature |
<table><tr><td>wires flexed -5...105 °C</td></tr><tr><td>wires at rest -30...105 °C</td></tr></table> |
| Protection |
IP 67 |
| Tests / approvals |
|
| MTTF |
347 |
| Mechanical data |
|
| Weight |
71.5 |
| Dimensions |
54 x 34 x 15 |
| Material |
polyamide reinforced glass-fiber |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
|
| Input |
Cable: 0.28 m; / Core ends with wire end sleeves |
