| Weight |
32.2 |
| Dimensions |
Ø 19 / L = 22 |
| Material |
aluminum |
| Tightening torque |
tightening torque screws: 80 Ncm |
| External diameter D |
19 |
| Inside diameter 1 |
6 |
| Inside diameter 2 |
6 |
| Clamping screw |
M3 x 4 - ISO 4029 (4x) |
| Length |
22 |
| Max. revolution, mechanical |
8000 |
| Max. axial shaft misalignment |
± 0,4 |
| Max. radial shaft misalignment |
± 0,25 |
| Max. angular displacement |
± 3,5 |
| Remarks |
| The data indicated apply to couplings with the above hub borings at an ambient temperature of 23 °C. | | The values of radial, angular and axial displacement are maximum values which must not reach their maximum simultaneously while in operation. |
|
| Pack quantity |
1 pcs. |
