| Weight |
29.9 |
| Dimensions |
Ø 30 / L = 22 |
| Material |
aluminum; PA |
| Tightening torque |
tightening torque screws: 120 Ncm; Spring disc coupling: 60 Ncm |
| External diameter D |
30 |
| Inside diameter 1 |
10 |
| Inside diameter 2 |
10 |
| Clamping screw |
M3 x 10 - ISO 4762 (2x) |
| Length |
22 |
| Max. revolution, mechanical |
12000 |
| Max. axial shaft misalignment |
± 0,4 |
| Max. radial shaft misalignment |
± 0,3 |
| Max. angular displacement |
± 2,5 |
| Rigidity of the torsion spring |
50 |
| Remarks |
| The data indicated apply to couplings with the above hub borings at an ambient temperature of 23 °C. | | The values of radial, angular and axial displacement are maximum values which must not reach their maximum simultaneously while in operation. |
|
| Pack quantity |
1 pcs. |
