| Weight |
58 |
| Dimensions |
Ø 30 / L = 38 |
| Material |
aluminum |
| Tightening torque |
tightening torque screws: 120 Ncm |
| External diameter D |
30 |
| Inside diameter 1 |
10 |
| Inside diameter 2 |
12,7 |
| Depth of the clamping hub |
9.6 |
| Clamping screw |
M4 x 12 - ISO 4762 (2x) |
| Length |
38 |
| Max. revolution, mechanical |
6000 |
| Max. axial shaft misalignment |
± 0,5 |
| Max. radial shaft misalignment |
± 0,35 |
| Max. angular displacement |
± 4,0 |
| Remarks |
| The data indicated apply to couplings with the above hub borings at an ambient temperature of 23 °C. | | The values of radial, angular and axial displacement are maximum values which must not reach their maximum simultaneously while in operation. |
|
| Pack quantity |
1 pcs. |
