| Housing |
rectangular |
| Dimensions |
48 x 48 x 107 |
| Application |
preset counter with 2 presets |
| Nominal voltage AC |
90...260 |
| Nominal frequency AC |
50...60 |
| Auxiliary energy for sensors DC |
24; (±15 %, 80 mA) |
| Number of inputs and outputs |
Number of digital inputs: 2; Number of relay outputs: 2 |
| Number of digital inputs |
2 |
| Number of relay outputs |
2 |
| Ambient temperature |
-20...65 |
| Storage temperature |
-25...75 |
| Max. relative air humidity |
93 |
| Protection |
IP 65; (on the front) |
| Protection rating terminals |
IP 00 |
| EMC |
| EN 55011 | class B | | EN 61000-6-2 | (with shielded control and signal cables) |
|
| Shock resistance |
|
| Vibration resistance |
| EN 60068-2-6 | 10...55 Hz / (1 mm / XYZ) |
|
| Weight |
214.5 |
| Housing |
rectangular |
| Type of mounting |
installation in panels or panel cutouts; (panel cutout: 45 x 45 mm) |
| Dimensions |
48 x 48 x 107 |
| Material |
housing: PC black |
| Display |
| 2 x 7-segment LCD display, green backlit 6-digit |
|
| Operating elements |
|
| Pack quantity |
1 pcs. |
| Connection |
plug-in screw terminals: 7 x ...2.5 mm² |
