| Number of inputs and outputs |
Number of analog outputs: 2 |
| Design |
integrated IO-Link master |
| Operating voltage |
18...30 DC; (to SELV/PELV) |
| Nominal voltage DC |
24 |
| Current consumption |
< 30 |
| Max. current load total |
0.83 |
| Number of inputs and outputs |
Number of analog outputs: 2 |
| Number of analog outputs |
2 |
| Analog current output |
4...20 |
| Max. load |
500 |
| Precision analog output |
0,25 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| Number of ports class A |
1 |
| Profiles |
| Common - I&D | Identification and Diagnosis |
|
| Min. process cycle time |
4.2 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1398 |
|
| Ambient temperature |
-25...60 |
| Storage temperature |
-40...70 |
| Max. relative air humidity |
90; (linearly decreasing to 50 % (40 °C) non condensing) |
| Protection |
IP 67; IP 69K |
| MTTF |
254 |
| UL approval |
| Ta | max. 55 °C | | Enclosure type | Type 1 | | voltage supply | Low Voltage / Limited Energy | | File number UL | E205959 |
|
| Weight |
91.45 |
| Housing |
rectangular |
| Dimensions |
62.7 x 30 x 23 |
| Material |
PA; stainless steel (1.4404 / 316L); FKM |
| Display |
| status | 1 x LED, red | | Power | 1 x LED, green |
|
| Remarks |
| Further information is available in the manual. | | the device complies with overvoltage category II |
|
| Notes |
This converter only works in combination with appropriately specified ifm sensors (see device catalog under "Downloads") |
| Pack quantity |
1 pcs. |
