Характеристики
| Connection | M12 Connector |
| Product designation | Wall passage |
Все характеристики
| Operating voltage | < 60 AC/DC |
| Max. current load total | 8; (Pin 1+3: 4 A; Pin 2+4: 4 A) |
| Ambient temperature | -40...85 |
| Protection | IP 65; IP 67 |
| Weight | 24.1 |
| Material | brass nickel-plated; sealing: FKM |
| Molded-body material | brass, nickel-plated |
| Tightening torque | 1 |
| Pack quantity | 1 pcs. |
| Connector: 1 x M12, straight; coding: A; Moulded body: brass, nickel-plated | |
| Connection | Connector: 1 x M12, straight; coding: A; Moulded body: brass, nickel-plated |
Приемущества
| User-friendly equipment of distributors and housings with connections for connectors |
| Easy and quick installation into the container wall |
| Robust metal version |
| High protection rating for the requirements of harsh industrial environments |
| Wide operating temperature range |
