| System |
gold-plated contacts |
| Radio approval for |
USA; Canada; EU/RED; Australia; Japan; Namibia; Brazil; China; India; Singapore; Mexico; South Africa; Malaysia; Vietnam; Chile; Thailand; Taiwan; South Korea; Indonesia; Argentina |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
18...30 DC |
| Nominal voltage DC |
24 |
| Current consumption |
30...830; (24 V DC, full load) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Parameter setting options |
process value recording |
| Communication interface |
IO-Link; Bluetooth |
| Transmission standard |
BLE 4.0; BLE 4.1; BLE 4.2; EDR 2.0; EDR 2.1 |
| Frequency band |
2,4 - 2,482 GHZ |
| Transmission power |
10; (10 dBm) |
| Range |
typ. 20 m |
| Transmission type |
COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud) |
| IO-Link revision |
1.0; 1.1 |
| SDCI standard |
IEC 61131-9 |
| Required master port class |
A |
| Ambient temperature |
-25...60 |
| Storage temperature |
-25...70 |
| Protection |
IP 67 |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-4 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 15 g (6 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 2 g (10...150 Hz) |
|
| MTTF |
285 |
| UL approval |
| Ta | max. 55 °C | | File number UL | E205959 |
|
| Weight |
88.5 |
| Dimensions |
63 x 30 x 24 |
| Material |
stainless steel (1.4404 / 316L); brass (2.0401); PA; PBT; FKM; sealing: FKM; |
| Display |
| Power | 1 x LED, green | | IO-Link | 1 x LED, yellow | | Bluetooth | 1 x LED, blue |
|
| Remarks |
| the device complies with overvoltage category II |
|
| Pack quantity |
1 pcs. |
