| System |
gold-plated contacts |
| Application |
Base station for Bluetooth adapters. The data collected by the connected adapters can be retrieved via Ethernet using IoT Core; can be used with moneo Cloud in combination with moneo edgeGateway AE2100 or moneo on-premises (from version 1.15) |
| Radio approval for |
EU/RED; Great Britain; USA; Canada; Japan; Namibia; Singapore; Australia; India; Vietnam; New Zealand; Indonesia; Malaysia; Thailand; Ukraine; Taiwan; Mexico; Argentina; Chile; South Korea; South Africa; China; Brazil |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
18...30 DC; (limitation due to ES1 and PS2) |
| Nominal voltage DC |
24 |
| Current consumption |
< 100 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Communication interface |
Ethernet; Bluetooth |
| Transmission standard |
BLE 5.0 |
| Frequency band |
2,4 GHZ |
| Transmission power |
10; (10 dBm) |
| Range |
typ. 20 m |
| Transmission standard |
10Base-T; 100Base-TX |
| Transmission rate |
10; 100 |
| Protocol |
MQTT JSON; IoT-Core |
| Factory settings |
| IP address: DHCP | | MAC address: see type label |
|
| Ambient temperature |
-25...60 |
| Storage temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 40 g, 6 ms / bump | | 50 g, 11 ms / single shock |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 2 g (10...150 Hz) |
|
| MTTF |
184 |
| UL approval |
|
| Weight |
469.4 |
| Material |
PBT; PC; stainless steel (1.4401 / 316); stainless steel (1.4567 / 304Cu); brass; PU; PTFE; FKM |
| Display |
| Power | LED, green | | warning / fault | LED, red | | Bluetooth | LED, blue |
|
| Pack quantity |
1 pcs. |
