| Application |
data storage via IO-Link |
| Operating voltage |
18...30 DC |
| Current consumption |
< 50 |
| Protection class |
III |
| Memory size |
1042432 |
| Memory type |
FRAM |
| Max. read cycles |
unlimited |
| Max. write cycles |
unlimited |
| Communication interface |
IO-Link |
| Transmission type |
COM3 (230,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
| Common - I&D | Identification and Diagnosis |
|
| SIO mode |
no |
| Required master port class |
A |
| Min. process cycle time |
5 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1423 |
|
| Ambient temperature |
-20...60 |
| Storage temperature |
-25...80 |
| Protection |
IP 67; IP 69K |
| EMC |
| EN IEC 61000-6-2 | | | EN IEC 61000-6-4 | |
|
| Shock resistance |
| EN 60068-2-27 | 40 g 6 ms / repetitive | | EN 60068-2-27 | 50 g 11 ms / not repetitive |
|
| Vibration resistance |
| EN 60068-2-6 | 20 g 10...2000 Hz |
|
| UL approval |
| Ta | -20...60 °C | | Enclosure type | Type 1 | | voltage supply | Limited Voltage/Current | | File number UL | E205959 |
|
| Weight |
59.8 |
| Housing |
rectangular |
| Mounting |
non-flush mountable |
| Dimensions |
20 x 7 x 48 |
| Material |
PBT; TPU (urethane); stainless steel |
| Display |
| Power | 1 x LED, green | | Memory access | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
