| Application |
decentralized display, preprocessing and conversion of analog signals |
| Nominal voltage DC |
24 |
| Current consumption |
120 |
| Reverse polarity protection |
yes |
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Input circuit of digital inputs |
IO-Link |
| Number of analog outputs |
1 |
| Analog current output |
4...20 |
| Max. load |
500 |
| Precision analog output |
0,25 |
| Resolution of analog output |
12 bit |
| Communication interface |
IO-Link |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 65596 |
|
| Transmission type |
COM3 (230,4 kBaud) |
| IO-Link revision |
1.1 |
| SIO mode |
no |
| Required master port class |
A/B |
| Process data analog |
2 |
| Min. process cycle time |
2 |
| Ambient temperature |
-25...60 |
| Storage temperature |
-25...85 |
| Max. relative air humidity |
95 |
| Max. height above sea level |
3000 |
| Protection |
IP 67; IP 65 |
| Weight |
51.709 |
| Material |
Housing materials: PA |
| Display |
| Output | LED, yellow | | Power | LED, green |
|
| Pack quantity |
1 pcs. |
| Socket |
Connector: M12; coding: A |
| plug |
Connector: M12; coding: A |
