| Application |
Display and transfer of machine states to higher-level evaluation software via IO-Link |
| Operating voltage |
18...30 DC; (to SELV/PELV) |
| Nominal voltage DC |
24 |
| Current consumption |
< 200 |
| Number of inputs and outputs |
Number of digital inputs: 6 |
| Number of digital inputs |
6 |
| Input current High |
6 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
| Common - I&D | Identification and Diagnosis |
|
| SIO mode |
yes |
| Required master port class |
A |
| Min. process cycle time |
8 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1700 |
|
| Ambient temperature |
-25...50 |
| Storage temperature |
-40...75 |
| Max. relative air humidity |
90 |
| Air pressure |
< 106 |
| Max. height above sea level |
2000 |
| Protection |
IP 65 |
| Weight |
412.9 |
| Dimensions |
Ø 70 / L = 244 |
| Material |
housing: ABS; lens: PC |
| Display |
| status | 1 x LED, green | | LED segment | 5 x 4 LED |
|
| Accessories (optional) |
| mounting base, E89060 | | wall bracket, E89061 | | Mounting adapter, E89063 | | bracket with lateral cable entry, E89064 | | mounting tube, E89065 | | mounting tube, E89066 | | mounting tube, E89067 |
|
| Remarks |
| Further information is available in the manual. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: M12; coding: A |
