| Application |
signaling machine conditions |
| Operating voltage |
18...30 DC; (to SELV/PELV ; "supply class 2" to cURus) |
| Nominal voltage DC |
24 |
| Current consumption |
< 90 |
| Switch-on peak current |
400 |
| Switch-on peak current duration |
50 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| SIO mode |
yes |
| Required master port class |
A |
| Min. process cycle time |
8 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1054 |
|
| Ambient temperature |
-25...50 |
| Storage temperature |
-40...75 |
| Max. relative air humidity |
90 |
| Max. height above sea level |
4000 |
| Protection |
IP 67 |
| Degree of soiling |
2 |
| MTTF |
488 |
| Weight |
153 |
| Dimensions |
Ø 56 / L = 61 |
| Material |
housing: ABS; lens: PC |
| Display |
| LED segment, red / green / yellow / blue / lilac / cyan / white |
|
| Accessories (optional) |
| mounting base, E89060 | | wall bracket, E89061 | | Mounting adapter, E89063 | | bracket with lateral cable entry, E89064 | | mounting tube, E89065 | | mounting tube, E89066 | | mounting tube, E89067 | | mounting base, E89080 |
|
| Remarks |
| Further information is available in the manual. |
|
| Pack quantity |
1 pcs. |
| IO-Link |
Connector: M12; coding: A |
