| Design |
housing for DIN rail mounting |
| Operating voltage |
to SELV/PELV |
| Nominal voltage DC |
24 |
| Input voltage DC |
19.2...30 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Mains buffering time (nominal voltage 24 V DC) |
10 |
| Input current (nominal voltage 24 V DC) |
40 |
| Closed-circuit current |
10 |
| Power loss (nominal voltage 24 V DC) |
0.48 |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SIO mode |
no |
| Min. process cycle time |
20 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| Default | 892 | | Status B | 1573 |
|
| Note |
| For further information please see the IODD PDF file at "Downloads" |
|
| Ambient temperature |
-25...60 |
| Storage temperature |
-40...70 |
| Protection |
IP 20; (on the front) |
| Degree of soiling |
2 |
| EMC |
| EN 61000-6-3 | radiation of interference | | EN 61000-6-2 | noise immunity |
|
| Weight |
73 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
80 x 12.5 x 98 |
| Display |
| status | 1 x LED, red / green / orange |
|
| Pack quantity |
1 pcs. |
| Connection |
push-in terminals: |
