| Design |
housing for DIN rail mounting |
| Operating voltage |
to SELV/PELV |
| Nominal voltage DC |
24 |
| Input voltage DC |
19.2...30 |
| Protection class |
III |
| Mains buffering time (nominal voltage 24 V DC) |
10 |
| Closed-circuit current |
8 |
| Power loss (nominal voltage 24 V DC) |
1.26 |
| Number of channels |
2 |
| Nominal current |
6 |
| Nominal current (Fail Safe Element) |
6 |
| Load capacitance, total |
20 |
| Ambient temperature |
-25...60 |
| Storage temperature |
-40...70 |
| Protection |
IP 20; (on the front) |
| Degree of soiling |
2 |
| EMC |
| EN 61000-6-3 | radiation of interference | | EN 61000-6-2 | noise immunity |
|
| Weight |
73 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
80 x 12.5 x 98.5 |
| Display |
| status | 2 x LED, red / green / orange |
|
| Operating elements |
|
| Pack quantity |
1 pcs. |
| Connection |
push-in terminals: |
