| Number of inputs and outputs |
Number of analog outputs: 2 |
| Process connection |
G 3/4 |
| Media |
mineral oils; synthetic esters; biodegradable oils |
| Tank pressure |
|
| Medium temperature |
-40...105 |
| Operating voltage |
9...33 DC |
| Current consumption |
< 25 |
| Protection class |
III |
| Reverse polarity protection |
no |
| Measuring principle |
capacitive |
| Number of inputs and outputs |
Number of analog outputs: 2 |
| Total number of outputs |
2 |
| Number of analog outputs |
2 |
| Analog current output |
4...20 |
| Max. load |
(Ub - 8) x 25 |
| Resolution of analog output |
φ: 1% / T: 0.1 K |
| Measuring range |
-20...120 |
| Accuracy |
φ: ± 3 % / T: ± 2 % |
| Response time |
1.3 |
| Ambient temperature |
-40...85 |
| Storage temperature |
-40...85 |
| Max. relative air humidity |
100 |
| Protection |
IP 67 |
| EMC |
| EN 13309 | | | IEC 61000-6-2 | : 2005 | | IEC 61000-6-4 | : 2006 + AMD1: 2010 |
|
| Vibration resistance |
| test following DIN EN 60068-2-6 | |
|
| MTTF |
90 |
| Weight |
169 |
| Materials (wetted parts) |
aluminum; HNBR; polyurethane resin; epoxy resin |
| Process connection |
G 3/4 |
| Remarks |
| Accuracy values expressed in percent refer to the measuring span |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
