| Measuring range of vibration |
-80...80; (-50...50 g when connected to a VSE) |
| Frequency range |
1.5...12000 |
| Measuring principle |
piezoelectric |
| Communication interface |
IEPE |
| System |
screened cable |
| Design |
for connection to external diagnostic electronics VSE |
| Bias voltage DC |
10...12 |
| Current consumption |
0.5...8 |
| Min. insulation resistance |
100; (500 V DC) |
| Reverse polarity protection |
yes |
| Measuring range of vibration |
-80...80; (-50...50 g when connected to a VSE) |
| Frequency range |
1.5...12000 |
| Measuring principle |
piezoelectric |
| Noise density |
0.1 |
| Max. transverse sensitivity |
5 |
| Minimum measuring time |
2 |
| Number of measurement axes |
1 |
| Accuracy |
± 10 % |
| Measuring sensitivity |
100 mV/g |
| Communication interface |
IEPE |
| Ambient temperature |
-50...150 |
| Storage temperature |
-20...80 |
| Max. relative air humidity |
80; (50 °C; 50 % non condensing) |
| Protection |
IP 68; (water-proof up to 100 m 10 bar) |
| EMC |
|
| Shock resistance |
|
| Weight |
1892 |
| Housing |
rectangular |
| Type of mounting |
M8 x 1,25 |
| Dimensions |
30 x 25 x 64 |
| Material |
housing: stainless steel |
| Tightening torque |
8 |
| Pack quantity |
1 pcs. |
|
Cable: 25 m, PTFE coated, blue, screened |
