| Measuring range of vibration |
-50...50 |
| Frequency range |
2...10000 |
| Measuring principle |
piezoelectric |
| Design |
for connection to external diagnostic electronics VSExxx |
| Switching amplifiers |
Connection to intrinsically safe supply isolators (Ex ia) |
| Operating voltage |
10...12 DC |
| Current consumption |
0.5...8 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Max. load |
200 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring range of vibration |
-50...50 |
| Frequency range |
2...10000 |
| Measuring principle |
piezoelectric |
| Sensitivity |
100 |
| Noise density |
0.1 |
| Max. transverse sensitivity |
5 |
| Minimum measuring time |
2 |
| Number of measurement axes |
1 |
| Ambient temperature |
-55...90 |
| Storage temperature |
-55...90 |
| Protection |
IP 68; (1D application: IP 65) |
| Approval |
Baseefa12ATEX0247; IECEx BAS 12.0132 |
| ATEX marking |
I M1 Ex ia I Ma (-55°C < Ta < +90°C) |
| EMC |
|
| Shock resistance |
|
| Weight |
669 |
| Type of mounting |
M8 x 1,25 |
| Dimensions |
30 x 25.5 x 64.7 |
| Material |
housing: stainless steel |
| Tightening torque |
8 |
| Accessories (optional) |
|
| Pack quantity |
1 pcs. |
|
Cable: 10 m, PUR |
