| Radio approval for |
USA; Canada; EU/RED; Australia; Brazil |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
3.6 DC; (lithium thionyl chloride battery lithium thionyl chloride battery; battery life > 4 years; (depending on environmental conditions & settings); battery cannot be replaced) |
| Current consumption |
< 200 |
| Protection class |
III |
| Parameter setting options |
MQTT; ifm IoTcore |
| Communication interface |
WLAN; Mobile networks; Ethernet |
| Type of connector |
RJ45 |
| Protocol |
TCP/IP |
| Usage type |
Data transmission |
| Frequency band |
2,4 GHz |
| Safety standard |
AES-128 |
| Protocol |
proprietary |
| Usage type |
sensor connection |
| Note on interfaces |
| number of maximum connections of sensors: 30 |
|
| Transmission standard |
2G quadband GSM; LTE Cat-M1; NarrowBand-IoT |
| Usage type |
Data transmission |
| Type of connector |
USB A |
| Usage type |
firmware update |
| Frequency band |
2,4 GHz |
| Safety standard |
WPA2 |
| Usage type |
Data transmission |
| Ambient temperature |
0...50 |
| Storage temperature |
-40...85 |
| Protection |
IP 20 |
| EMC |
| DIN EN 301489-1 | | | DIN EN 301489-17 | | | DIN EN 301489-52 | |
|
| Weight |
423 |
| Dimensions |
Ø 95 |
| Material |
PA; ABS |
| Display |
|
| Items supplied |
| Mounting accessories, for wall mounting | | Power supply |
|
| Remarks |
|
| Pack quantity |
1 pcs. |
