| Technical Data |
|
| Stroke range |
1001990 |
| Cylinder diameter |
50200 |
| Supported kinematic |
Lifting columnParallel kinematics |
| Reverse polarity protection |
For operating voltage |
| Operating pressure |
48 |
| Max. travel speed |
1 |
| Operational voltage range DC |
21.626.4 |
| Duty cycle |
100% |
| Nominal operating voltage DC |
24 |
| Residual ripple |
5 % |
| Current consumption with no-load outputs |
2000 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [6:4:4] |
| LABS (PWIS) conformity |
VDMA24364 zone III |
| Storage temperature |
-2070 |
| Degree of protection |
IP65 |
| Note on degree of protection |
IP20 for safety relay unit PNOZIP20 for control system CMCB-...-CIP20 for controller CECC-DIP54 for control system CMCB-...-CCIn assembled state |
| Ambient temperature |
050 |
| Load |
25999 |
| Transmission ratio of kinematics |
1:5 for lifting columns1:1 - 1:5 for parallel kinematics system |
| Product weight |
480060500 |
| Note on materials |
RoHS-compliant |
