| Technical Data |
|
| Size |
Standard |
| Nominal size |
5.1 |
| Mounting position |
optional |
| Design |
Push-pull principle |
| Size of pack |
1 |
| Operating pressure complete temperature range |
-13.775145 |
| Note on operating pressure |
Water: max. 0.6 MPa at max. 50°C |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-]Water (liquid, ice-free) |
| Note on operating and pilot medium |
Lubricated operation possible |
| Corrosion resistance class CRC |
4 - Very high corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Suitable for use with food |
See supplementary material information |
| Ambient temperature |
-15120 |
| Product weight |
12 |
| Suitable cables |
PFAN |
| Type of mounting |
External hexagon, size 14 mm |
| Pneumatic connection, port 1 |
Male thread R1/8 |
| Pneumatic connection, port 2 |
For tubing outside diameter of 8 mm |
| Material screwed plug |
High-alloy stainless steel |
| Note on materials |
RoHS-compliant |
| Material housing |
High-alloy stainless steel |
| Material release ring |
High-alloy stainless steel |
| Material tubing seal |
FPM |
| Material tubing clamp component |
High-alloy stainless steel |
| Thrust ring material |
High-alloy stainless steel |
