SKU: 177721
GTIN: 4052568038663
Характеристики
| Pneumatic connection, port 1 | Push-in sleeve CQ-15 |
| Pneumatic connection, port 2 | Push-in sleeve QS-12 |
| Temperature-dependent operating pressure | -0.95, 15 |
| Ambient temperature | -25, 70 |
| Nominal size | 8 |
Все характеристики
| Technical Data | |
| Nominal size | 8 |
| Mounting position | optional |
| Size of pack | 1 |
| Design | Push-pull principle |
| Operating pressure complete temperature range | -0.957 |
| Temperature-dependent operating pressure | -0.9515 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -2570 |
| Product weight | 4 |
| Pneumatic connection, port 1 | Push-in sleeve CQ-15 |
| Pneumatic connection, port 2 | Push-in sleeve QS-12 |
| Note on materials | RoHS-compliant |
| Material housing | POM |
Приемущества
| For pipes PQ-PA, PQ-AL and tubing PAN and PUN |
| Operating media: compressed air, vacuum, liquid media |
| POM |
| Straight design, L-shaped, T-shaped |
