| Application |
|
| System |
Free from silicone; gold-plated contacts |
| Free from silicone |
yes |
| Electrical data |
|
| Operating voltage |
< 60 AC/DC; (cULus: 30 AC / 42 DC) |
| Protection class |
II |
| Max. current load per module/slot |
4 |
| Max. current load total |
4 |
| Overall current rating (UL) |
3 |
| Operating conditions |
|
| Ambient temperature |
-25...100 |
| Note on ambient temperature |
<table><tr><td>cULus: ...65 °C</td></tr></table> |
| Storage temperature |
-25...55 |
| Storage humidity |
10...100 |
| Other climatic conditions for storage according to stated class |
<table><tr><td>1K22/ DIN 60721-3-1</td></tr></table> |
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| Tests / approvals |
|
| UL approval |
<table><tr><td>voltage supply</td><td>Class 2 </td></tr><tr><td>File number UL</td><td>E191684 </td></tr></table> |
| Mechanical data |
|
| Weight |
34.1 |
| Material |
housing: PA Halogen-free; sealing: EPDM |
| Molded-body material |
PA, Halogen-free |
| Material nut |
stainless steel (1.4404 / 316L) |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection - Socket |
|
| Electrical connection - plug |
|
| Connection |
Connector: 1 x M12; coding: A; Moulded body: PA, Halogen-free; Locking: stainless steel (1.4404 / 316L); Contacts: gold-plated; Tightening torque: 0.6...1.2 Nm |
