| Application |
Detection of objects on transport equipment |
| Radio approval for |
USA; Canada; EU/RED; Australia; Japan; China; Taiwan; India; Singapore; Ukraine |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
19.2...28.8 DC; (Supply only via the DTE10x evaluation unit (to EN 60950-1)) |
| Current consumption |
< 50 |
| Protection class |
III |
| Operating frequency |
13,56 |
| RFID standard |
ISO 15693 |
| Distance write/read head front |
160 |
| Distance write/read head side |
120 |
| Distance to the ID tag |
|
| Communication interface |
DATA / DTE10x |
| Ambient temperature |
-20...60 |
| Storage temperature |
-25...80 |
| Protection |
IP 67; IP 69K |
| Shock resistance |
| EN 60068-2-27 | 50 g 11 ms / 40 g (6 ms, continuous) |
|
| Vibration resistance |
| EN 60068-2-6 | 20 g 10...2000 Hz |
|
| MTTF |
556 |
| Weight |
175.8 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M30 x 1.5 / L = 70 |
| Thread designation |
M30 x 1.5 |
| Material |
housing: stainless steel; Protective cover: PPS |
| Display |
| Power | 1 x LED, green | | tag communication | 1 x LED, yellow |
|
| Items supplied |
|
| Remarks |
| Singapore Not approved for operation, for export only. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
