| Type of light |
Infrared light |
| Electrical design |
PNP |
| Protection |
IP 65 |
| Protective function |
Access prevention body protection |
| Operating voltage tolerance |
20 |
| Operating voltage |
24 DC |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
< 10 |
| Type of light |
Infrared light |
| Wave length |
950 |
| Current consumption |
250 |
| Current consumption |
125 |
| Electrical design |
PNP |
| Number of OSSD outputs |
2 |
| Max. current load per OSSD output |
500; (24 V) |
| Short-circuit protection |
yes |
| Protected area height |
510 |
| Number of beams |
2 |
| Protection area width (low light intensity) |
8...30 |
| Protection area width (high light intensity) |
18...60 |
| Response time |
7 |
| Applications |
Class C to EN 60654-1 weatherproof application |
| Ambient temperature |
-10...55 |
| Max. relative air humidity |
95 |
| Protection |
IP 65 |
| EMC |
|
| Shock resistance |
|
| Vibration resistance |
|
| ESPE type (IEC 61496-1) |
4 |
| Complies with the requirements |
| ISO 13849-1: 2015 Category 4, PL e | | IEC 61508 SIL 3 | | IEC 62061 SIL 3 |
|
| MIssion time TM |
175200 |
| PFH |
7,5E-09 |
| Weight |
5060 |
| Dimensions |
736 x 50 x 60 |
| Material |
housing: aluminum; front lens: PC |
| Length L |
736 |
| Display |
| transmitter | 4 x LED | | receiver | 6 x LED | | receiver | LC display |
|
| Items supplied |
| Assembly angle: 4 | | Slot nuts: 4 |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Maximum cable length: 100 m; for wire cross-section 1 mm² |
| Connection |
Connector: 1 x M12; coding: A |
