| Electrical design |
NPN |
| Output function |
normally closed |
| Sensing range |
8 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 84 |
| Operating voltage |
10...36 DC; (cULus - Class 2 source required) |
| Current consumption |
< 10 (24 V DC) / < 15 (36 V DC) |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
NPN |
| Output function |
normally closed |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Switching frequency DC |
50 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
| Sensing range |
8 |
| Sensing range adjustable |
yes |
| Factory setting sensing range |
8 |
| Real sensing range Sr |
8 ± 10 % |
| Operating distance |
0...6.5 |
| Correction factor |
glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
| Hysteresis |
1...15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
|
| MTTF |
671 |
| Weight |
125 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M18 x 1 / L = 84 |
| Thread designation |
M18 x 1 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PVC; 3 x 0.34 mm² |
