| Process connection |
threaded connection G 1/2 Internal thread |
| Process connection |
threaded connection G 1/2 Internal thread |
| Measuring range |
0.1...25 |
| System |
gold-plated contacts |
| Application |
Industrial applications; Cooling water control |
| Installation |
connection to pipe by means of an adapter; tube connection |
| Measuring parameters |
flow; temperature; pressure; totalizer |
| Control |
manual |
| Media |
Conductive liquids; water-based media; glycol solutions |
| Medium temperature |
-10...70 |
| Pressure rating |
10 |
| Components |
| Magnetic-inductive flow meter, SM6000 | | Electronic pressure monitor, PN7094 | | filter | | water stop valve | | backstop |
|
| Output signal |
switching signal; analog signal; pulse signal; IO-Link |
| Output function |
normally open / closed; (configurable) |
| Measuring range |
-1...10 |
| Measuring range |
-20...80 |
| Ambient temperature |
-10...50 |
| Storage temperature |
-25...80 |
| Protection |
IP 67; (sensors) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | |
|
| Pressure equipment directive |
sound engineering practice; can be used for group 2 fluids; group 1 fluids on request |
| Weight |
3388.5 |
| Type of mounting |
Mounting bracket |
| Material |
stainless steel (1.4404 / 316L); PBT-GF20; PBT; PC; FKM; TPE; bronze (2.1096.01) |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); PEEK; FKM; NBR; PVDF; ceramics |
| Pack quantity |
1 pcs. |
|
Connector: 3 x M12; Contacts: gold-plated |
